Globe valves
Components
| 1 | Body | Cast iron |
| 2 | Body Seat | Bronze |
| 3 | Disc | Bronze |
| 4 | Stem | Brass |
| 5 | Bonnet | Cast iron |
| 6 | Hand wheel | Cast iron or ductile iron |
Application
| 1 | Design according to ANSI B16.10 |
| 2 | Flange end ANSI B16.1 |
| 3 | Nominal Pressure 125PSI |
Test
| Working Pressure | 125PSI | |
| Test Pressure | Shell | 300PSI |
| Seat | 200PSI |
Dimensions Unit: mm
| DN | 2″ | 2-1/2″ | 3″ | 4″ | 5″ | 6″ | 8″ | 10″ | 12″ |
| L | 8″ | 8-1/2″ | 9-1/2″ | 11-1/2″ | 13″ | 14″ | 19-1/2″ | 24-1/2″ | 27-1/2″ |
| H | 10-3/4″ | 11-3/4″ | 12-1/4″ | 13-7/8″ | 14-3/4″ | 16-3/4″ | 20-1/4″ | 24-1/2″ | 30″ |
| D | 6″ | 7″ | 7-1/2″ | 9″ | 10″ | 11″ | 13-1/2″ | 16″ | 19″ |
| g | 4-3/4″ | 5-1/2″ | 6″ | 7-1/2″ | 8-1/2″ | 9-1/2″ | 11-3/4″ | 14-1/4″ | 17″ |
| C | 7″ | 7″ | 8″ | 10″ | 10″ | 12″ | 14″ | 16″ | 18″ |
