Valves
Gate/Globe/Check Valves And Strainers
Non-rising stem
gate valves ANSI125/150
Components
| 1 | Body | Cast iron or ductile iron |
| 2 | Seat | Brass |
| 3 | Disc | Cast iron or ductile iron |
| 4 | Stem | Carbon steel or stainless steel |
| 5 | Bonnet | Cast iron or ductile iron |
| 6 | Hand wheel | Cast iron or ductile iron |
Application
| 1 | Design according to ANSI B16.10 Class 125/Class 150 |
| 2 | Flange end face to ANSI B16.1 Class 125/Class 150 |
| 3 | For water,neutral liquids and oil,gas |
Test
| Working Pressure | 125PSI | 150PSI | |
| Test Pressure | Shell | 300PSI | |
| Seat | 200PSI | ||
Dimensions Unit: inch
| DN | L | H | C | D | K |
| 1-1/2″ | 6-1/2″ | 11-1/4″ | 7″ | 5″ | 3-7/8″ |
| 2″ | 7-1/64″ | 12″ | 7″ | 6″ | 4-3/4″ |
| 2-1/2″ | 7-1/2″ | 12-7/8″ | 7″ | 7″ | 5-1/2″ |
| 3″ | 8″ | 14″ | 8″ | 7-1/2″ | 6″ |
| 4″ | 9-1/64″ | 15-1/2″ | 8″ | 9″ | 7-1/2″ |
| 5″ | 10″ | 17-1/4″ | 10″ | 10″ | 8-1/2″ |
| 6″ | 10-1/2″ | 19-1/8″ | 12″ | 11″ | 9-1/2″ |
| 8″ | 11-1/2″ | 25-7/8″ | 14″ | 13-1/2″ | 11-3/4″ |
| 10″ | 13″ | 28-5/8″ | 16″ | 16″ | 14-1/4″ |
| 12″ | 14-1/64″ | 32-1/2″ | 18″ | 19″ | 17″ |
