Non-rising stem Resilient soft seated
gate valve ANSI125/150
Components
| 1 | Body | Cast iron or Ductile iron |
| 2 | Disc | Ductile iron with NBR/EPDM |
| 3 | Bonnet | Cast iron or Ductile iron |
| 4 | Stem | stainless steel |
| 5 | Gland | Cast iron or Ductile iron |
| 6 | Hand wheel | Cast iron or Ductile iron |
Application
| 1 | Face to face is according to ANSI B 16.10 |
| 2 | Flange drilled is according to ANSI B16.1/B 16.5 |
| 3 | Class 125:Falt face flange |
| 4 | Class 150:Raised face flange |
Test
| Working Pressure | 125PSI | |
| Test Pressure | Shell | 300PSI |
| Seat | 200PSI |
Dimensions Unit: mm
| DN | 2″ | 2-1/2″ | 3″ | 4″ | 5″ | 6″ | 8″ | 10″ | 12″ |
| L | 7-1/64″ | 7-1/2″ | 8″ | 9″ | 10″ | 10-1/2″ | 11-1/2″ | 13″ | 14-1/64″ |
| H | 11″ | 11-1/5″ | 11-3/5″ | 12-4/5″ | 14-4/5″ | 16-9/10″ | 21″ | 24-1/5″ | 27-1/5″ |
| D125LBS | 6″ | 7″ | 7-1/2″ | 9″ | 10″ | 11″ | 13-1/2″ | 16″ | 19″ |
| D150LBS | 6″ | 7″ | 7-1/2″ | 9″ | 10″ | 11″ | 13-1/2″ | 16″ | 19″ |
| C | 7-9/10″ | 7-9/10″ | 9-4/5″ | 11″ | 12-3/5″ | 12-3/5″ | 13-4/5″ | 16″ | 17-7/10″ |
