Non-rising stem resilient soft seated
gate valves BS5163
Components
| 1 | Body | Cast iron or ductile iron |
| 2 | Disc | Ductile iron with NBR/EPDM |
| 3 | Bonnet | Cast iron or Ductile iron |
| 4 | Stem | Stainless steel |
| 5 | O-ring | NBR |
| 6 | Gland | Cast iron or Ductile iron |
| 7 | Hand wheel | Cast iron or Ductile iron |
Application
| 1 | Face to face is according to BS5163:1986 |
| 2 | Flange drilled is according to BS4504 |
Test
| Working pressure | PN10 | PN16 |
| Shell pressure | 15bars | 24bars |
| Seat pressure | 11bars | 17.6bars |
Dimensions Unit: mm
| DN | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| L | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 |
| H | 279 | 285 | 294 | 324 | 375 | 429 | 531 | 614 | 690 |
| D(PN10) | 165 | 185 | 200 | 220 | 250 | 285 | 340 | 395 | 445 |
| D(PN16) | 165 | 185 | 200 | 220 | 250 | 285 | 340 | 405 | 460 |
| K(PN10) | 125 | 145 | 160 | 180 | 210 | 240 | 295 | 350 | 400 |
| K(PN16) | 125 | 145 | 160 | 180 | 210 | 240 | 295 | 355 | 400 |
| g | 102 | 122 | 138 | 158 | 188 | 212 | 268 | 320 | 378 |
